Brilliant Power

Model: 0.08 × 625 (960)

0.5-4 × 1000 × 2000

Also known as cable insulating paper. An insulating paper used for high voltage power cables, control cables and signal cables. It is wrapped in the outermost layer of the cable to protect the insulation layer of the conductor core from moisture invasion and damage. It is web paper. The quantitation was 45-175g/m2. The paper is tough and even. It has high tensile, flexural and tear strength. It does not contain metal, sand and conductive acidic substances. High dielectric constant. Low power factor. The stability of paper is good when it is treated with insulating liquid. The varieties are divided according to different thickness or color. Unbleached kraft softwood pulp is used as raw material. After free beating, it is made on a long web paper machine without sizing and filling. Used for turn to turn insulation of wire or cable.

Crepe paper model: 0.05 × 25 (40)

Oil filter paper

1、 High grade thick quick cotton oil filter paper:

The oil filter paper produced by our company has a history of more than 30 years and is refined and processed from pure cotton fiber after eight times of purification. It is widely used for filtering transformer oil, turbine oil, aircraft, automobile, tractor oil, refinery, precision instruments, waste oil, chemical dyes and other oils. The size and variety of oil filter paper produced are more than 80. It is white and transparent without impurities; The products have passed the appraisal and meet the national standards, selling well all over the country, and some products have entered the international market. (please specify if drilling is required.)

2、 Quality index of cotton oil filter paper

1. Quantitation (g/m2): 270 g ± 5 g.

2. Air permeability (mm/min): 3500-6000.

3. Thickness (mm): 0.65-0.73.

4. The water absorption (mm/10 min) is greater than 80.

5. PH: neutral.

6. Burst resistance (kg/cm2): greater than 1.8-2.8

3、 Common specifications of cotton oil filter paper
